Turbo Series DC Charger

This charger combines AC & DC in one unit with multiple outputs for simultaneous charging. Features one AC Type 2 connector up to 22kW and two DC connectors (CCS2 & CHAdeMO) up to 60kW. Supports Ethernet, 4G, and WiFi communication with OCPP protocol and CMS. Intelligent App operation allows cashless payment. High protection grade IP54 (IP65 optional) with optional POS terminal. Includes Type A RCD protection, MID-certified AC meter, and ISO15118-ready for Plug & Charge. Flexible, secure, and efficient.

Technical Specifications:

• – AC & DC integration, multiple outputs

• – AC Type 2 connector, up to 22kW

• – DC CCS2 & CHAdeMO connectors, up to 60kW

• – App operation / RFID / Plug & Play

• – Ethernet / 4G / WiFi supported

• – OCPP protocol with CMS

• – Intelligent App operation, cashless payment

• – High protection IP54 (IP65 optional)

• – Optional POS terminal for payment

• – Type A RCD residual current protection

• – MID-certified AC meter

• – ISO15118 prepared for Plug & Charge
